Rebar Detailing Services

3D Rebar Detailing Services

Strict deadlines and having to respond quickly to project changes and information requests can lead to communication errors, coordination gaps, document mismatches, and improper information transfer. This eventually results in a waste of resources and materials as well as a delayed rebar schedule and reduced quality of construction documentation.

Our highly experienced and qualified rebar detailing experts provide high-quality 3D reinforcement modeling that helps contractors achieve a construction-ready level of accuracy as well as detailed rebar design and documentation for a variety of end uses, including high-rise buildings, schools, power plants, oil and gas plants, and refineries.

Rebar Drawings and Schedule Services

Our highly experienced rebar detailing experts provide shop drawings with a high level of detail on things like bends, lap splices, and shapes. This helps to generate secure and robust reinforcement solutions right from the level of the foundation to the ceiling of the top-most floor. With our detailed drawings, contractors can visualize the structures and can address project construction issues well in advance. Our drawings will guide the ironworkers on where exactly to place the steel.

Rebar Estimation Services

With our rebar estimation services, you get access to rebar detailing and fabrication drawings together with the relevant quantity takeoffs that help steel fabricators to better coordinate with contractors and builders. We will provide comprehensive rebar estimations and information on all the materials that are required for the project. We will calculate and provide accurate estimates or quotes for materials, accessories, and erection costs. With our services, you can be sure that your project will run most cost-effectively and that it will be delivered on time. We also provide rebar detailing solutions that adhere to the AASHTO, RSIO, ASTM, ACI, CRSI, and BS 8666 standards, among others.

Other Services

As well as the services listed above, our rebar detailers are also experts in -

1. Providing rebar shop drawings
2. Total rebar estimation services
3. Providing foundation details
4. Footing detailing services
5. Providing bar bending schedules
6. Providing roof truss and joint details
7. Concrete masonry detailing services
8. Providing retaining walls detailing services
9. Quality take-offs & as-built drawings services
10. Providing rebar 2D & 3D modeling services
11. Providing bar listing in ASA format
12. Performing 3d modeling of rebar using Tekla Structures
